New
FCB-ER9100
•4K 60
Unique 4K 60fps camera
•Optical zoom
10x
Wide angle 70°
•Size & Housing
Smallest 4K camera module
•High sensitivity
Starvis sensor , 1/2.8’’ image sensor (IMX-778 with AR coating)
High NIR performance
•Image stabilizer
Super/Super+ image stabilizer
•Feature rich
ICR ON with colour, Spot 3A, Boresight correction, Rolling shutter compensation
WDR, De-fog, E-flip, E-Pan/Tilt , Privacy zone Masking, IR Cut Removal…
•HDMI output
Same pinout as ER9500, easy transition from FCB-ER8530/ES8230
Key Features
Specifications
Downloads
| Key Features | resolution, compact size, optical zoom, image stabilization, sensor, HDMI video output, WDR, HFOV |
|---|---|
| Sensor | 1/2.8'' Exmor R Starvis Gen 3 |
| Resolution | |
| Video format | 4K, 1080p |
| Speed | |
| Optical zoom (lens) | 10x |
| Digital zoom | |
| Super resolution zoom | |
| Storage | |
| Lens | |
| Live view | |
| Width | 50 |
| Height | 58 |
| Depth | 80 |
| Weight | 250g |
| Interface | |
| Video output | HDMI (*) *1 Video is output in the TMDS signal format used by HDMI. |
| Partial scan/binning | |
| IEEE1588 compliant | |
| HW & SW trigger | |
| Noise filter | |
| DC 12 V (PoE) | |
| Shading/ defect correction | |
| Frame accumulation | |
| WDR | |
| LUT | |
| FOV | 70° |
| External synchronization | |
| Power consumption | |
| Image stabilization | |
| Noise reduction | |
| Visca command | |
| Sensitivity | |
| Others | ICR ON with colour, Spot 3A, Boresight correction, Rolling shutter compensation |
| accuracy | |
| distance range |
