Bright, Fast, and Robust 28x Zoom Lens -
The camera incorporates a new 28x bright zoom lens with f=1.35. This lens has a fast zooming capability (2.5 seconds from tele end to wide end), and high durability.
Image Stabilisation -
In StableZoom™ mode, image stabilization starts naturally without bringing an abrupt change to the horizontal angle of view.
Digital Output -
The camera is equipped with a digital interface (Y/Cb/Cr 4:2:2) which is comparable to ITU-R BT656.
The video output is free from signal deterioration, and no external analog/digital converter is required between the camera and other equipment.
Enhanced Noise Reduction -
By combining 2D and 3D noise reduction, the camera offers a wide selection of noise-reduction settings, from Level 1 to Level 5. This lets you choose the best level according to current conditions.
High-resolution Images -
The camera achieves a high horizontal resolution of 550 TV lines to reproduce very clear and detailed images.
High-sensitivity Images -
The camera has high sensitivity - high enough for use in video security.
In particular, the FCB-EX985E and FCB-EX985EP achieve 0.25 lx (F1.35, 50IRE) by employing a Super HAD CCD II sensor and bright 28X lens
Advanced White Balance –
For the White Balance function, there are two different modes:
Outdoor Auto mode and Sodium Vapor Lamp mode. These modes are designed to adapt to changing natural light outdoors, and to changing sodium vapor lamp lighting, respectively.
Extended Operation Temperature -
The camera can operate in a range of temperature from -5°C to 60°C.
Temperature Readout –
The camera unit’s internal temperature can be read out via VISCA. This data can be used as reference data to activate peripherals such as a fan or heater inside the camera equipment.
Slow AE Response –
The camera’s Auto Exposure speed for adapting to changes in lighting conditions can be set as slow as required, even as slow as 10 minutes. The speed of adaptation should be slowed down under some conditions, such as an underground parking lot where the camera might otherwise miss some important images when car lights cause an abrupt change in lighting conditions.
Colour Enhancement –
Using the Colour Enhancement function, a full-colour image can be changed to black and white, and then inverted into two selected colours. This function can be used in applications for low-vision systems to assist people with weak eyesight to read using a camera and display, relieving them of eye strain.
- Gain Limit Setting
- Zoom Limit Setting
- Zoom Speed-up in Zoom Direct Mode (Focus Trace On/Off)
- Focus Compensation in ICR Mode
- Alarm Signal Output in Auto ICR Mode
- Image Stabilization Hold
- Auto IR-cut Filter Removal (Auto ICR)
- Advanced Spherical Privacy
- Zone Masking
- Electronic Flip (E-Flip)
- Multi-line On-screen Display
- Video Motion Detection
- Picture Freeze
- SMART (Sony Modular Automatic Lens Reset Technology)
NTSC (for FCB-EX985E)
PAL (for FCB-EX985EP)
1/4-type Super HAD CCD II
Effective picture elements
380,000 pixels (NTSC for FCB-EX985E)
440,000 pixels (PAL for FCB-EX985EP)
28x optical zoom lens
f=3.5 mm (wide) to 98.0 mm (tele)
F1.35 to F3.7
12 x (336x with optical zoom)
Minimum object distance
10 mm (wide) to 1,500 mm (tele)
*Default: 300 mm
Horizontal viewing angle
55.8 degrees (wide) to 2.1 degrees (tele)
550 TV lines
Auto (Sensitivity: normal, low), One-push AF, Manual, Infinity, Interval AF, Zoom Trigger AF, Focus Compensation in ICR On Mode
0.25 lx (F1.35, 50IRE)
VBS: 1.0 Vp-p (sync negative), Y/C
Y/Cb/Cr 4:2:2 (comparable to ITU -R BT656)
VISCA (TTL signal level)
Baud rate: 9.6 kbps, 19.2 kbps, 38.4 kbps
Stop bit: 1/2 bit selectable
1/1 sec to 1/10,000 sec, 22 steps
Auto/Manual/Max. Gain Limit (-3 dB to +28 dB, 2 dB steps)
Auto, Manual, Priority mode (shutter priority & iris priority), Bright, EV compensation, Slow AE
Auto, AT W, Indoor, Outdoor, Outdoor Auto, Sodium Vapor Lamp (fix/auto), One-push, Manual
More than 50 dB
E-Flip, Nega Art, Black & White, Mirror image, Colour Enhancement
Camera operation swich
Yes (Zoom Tele, Zoom Wide)
DC 6.0 V to 12.0 V
2.2 W (motors active: 4.6 W)
-5°C to +60°C
-20°C to +60°C
238 g (8.4 oz)
Dimensions (W x H x D)
50.0 x 57.5 x 89.8 mm
(2 x 2 3/8 x 3 5/8 inches)
Wide-D Auto mode
Wide-D IS/PS mode
Enhanced Noise Reduction
Spherical Privacy Zone Masking
Slow AE response
Yes (Longer than 10 minutes)
Yes (20 characters/line, max. 11 lines)
Camera mode display
Yes (English*/Chinese) *default
Key switch control
Yes (Auto) for FCB-EX985E
